SKU: 850-68026C
  • Support 2x LGA1356 E5-2400 v2 / 1xE5-2403v2 installed
  • Max: 384GB / 12x memory slots / 1x DDR3L-1600 4GB installed
  • 4x 3.5" SATA drive bays
  • HP B120i SATA Controller
  • 1-year on-site
Our Price: Login to see price
Discontinued - Not orderable


Specifications

Type
Server
Recommended Use
Small business, corporate business
Product Form Factor
Rack-mountable - 1U
Server Scalability
2-way
Front Accessible Bays Qty
1
Hot-Swap Bays Qty
4
Localization
United States
Processor / Chipset
CPU
Intel Xeon E5-2403V2 / 1.8 GHz
Number of Cores
Quad-Core
CPU Qty
1
Max CPU Qty
2
CPU Upgradability
Upgradable
Processor Main Features
Intel QuickPath Interconnect
Cache Memory
Installed Size
L3 cache - 10 MB
Cache Per Processor
10 MB
RAM
Installed Size
4 GB / 192 GB (max)
Technology
DDR3 SDRAM
Memory Speed
1333 MHz
Memory Specification Compliance
PC3L-12800
Form Factor
DIMM 240-pin
Features
Registered, low-voltage
Configuration Features
1 x 4 GB
RAM Supported
PC3-10600 - 384 GB - low voltage - Load-Reduced
PC3-12800 - 192 GB - registered
PC3-10600 - 96 GB - low voltage - unbuffered - ECC
PC3-10600 - 192 GB - low voltage - registered
PC3-12800 - 96 GB - unbuffered - ECC
Hard Drive
Type
No HDD
Storage Controller
Type
1 x SATA - integrated - PCI Express 2.0 x4
Controller Interface Type
SATA 3Gb/s
Storage Controller Name
HP Dynamic Smart Array B120i
Channel Qty
6
RAID Level
RAID 0, RAID 1, RAID 10
Monitor
Monitor Type
None.
Graphics Controller
Type
Integrated
Graphics Processor
Matrox G200
Video Interfaces
VGA
Networking
Type
Integrated
Interface (Bus) Type
PCI Express 2.0 x4
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
HP 366i
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 4
Features
Wake on LAN (WoL), PXE support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1as, IEEE 802.3az
Expansion / Connectivity
Bays
1 (total) / 1 (free) x external 5.25"
4 (total) / 4 (free) x hot-swap 3.5" LFF
Slots
12 (total) / 11 (free) x DIMM 240-pin
2 (total) / 1 (free) x CPU
1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height
1 (total) / 1 (free) x PCIe 2.0 x8 - low-profile ( x4 mode )
1 (total) / 1 (free) x SD card
Interfaces
2 x VGA ( 1 front, 1 rear )
1 x serial
4 x LAN (Gigabit Ethernet)
1 x HP iLO
7 x USB 2.0 ( 2 front, 4 rear, 1 internal )
Miscellaneous
Included Accessories
HP Easy Install Rail kit
Features
Administrator password, power-on password, serial port I/O control, 92% efficiency power supply
Compliant Standards
ACPI 2.0b, FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 9254, CNS 13438
Power
Device Type
Power supply - hot-plug
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
Installed Qty
1
Max Supported Qty
2
Nominal Voltage
AC 120/230 V ( 50/60 Hz )
Power Provided
460 Watt
80 PLUS Certification
80 PLUS Gold
Operating System / Software
OS Certified
SuSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris
Manufacturer Warranty
Service & Support
3 years warranty
Service & Support Details
Limited warranty - parts and labor - 1 year - on-site - response time: next business day
Limited warranty - parts - 3 years
Dimensions & Weight
Depth
29.5 in
Height
1.7 in
Weight
30.1 lbs
Environmental Parameters
Min Operating Temperature
50 °F
Max Operating Temperature
95 °F
Humidity Range Operating
10 - 90% (non-condensing)
Sound Emission
33 dBA

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

  • Warranty Length: 3 years
  • Warranty Provider: HP
  • Service Contact: HP 800-474-6836
  • Technical Support: HP (208) 323-2551

Package Contents

  • HP ProLiant DL360e Gen8 E5-2403v2 4GB no HDD 1U w/460W Server
