SKU: 850-11737E
  • 2x LGA2011-3 E5-2600 v4 / v3 series
  • Max 1TB / 16 Dimm DDR4 2133/1866/1600/1333MHz ECC Registered
  • 36 x 3.5" SAS/SATA bays - Hot Swap - RAID 0, 1, 5, 6, 10, 50 and 60 - LSI 3108
  • Intel X540 Dual-Port 10GBase-T
  • Integrated IPMI 2.0 with KVM and Dedicated LAN
Our Price: Login to see price
Discontinued - Not orderable


Specifications

Server Case Form Factor
  • 4U
  • 17.2" x 7" x 27.5" (W x H x D)
Processor
  • Intel Xeon processor E5-2600 v4
  • Intel Xeon processor E5-2600 v3
  • Dual (Not Included)
Chipset
Intel C612
Bios
128Mb SPI Flash EEPROM with AMI BIOS
Type of Memory Supported
    288-pin DDR4 2133/1866/1600MHz ECC LRDIMM
      or
    288-pin DDR4 2133/1866/1600MHz ECC RDIMM
Maximum Memory Supported
    ECC LRDIMM: 1TB
      or
    ECC RDIMM: 512GB
Number of Memory Slots
16
Slots
  • 1x PCI-E 3.0 x16 slot
  • 6x PCI-E 3.0 x8 slots
  • Slot 1 & 2 occupied by controller and JBOD Expansion Port
Rear I/O Ports
  • 2 x USB 3.0
  • 2 x USB 2.0
  • 1 x Serial port
  • 1 x 15-pin VGA
  • 2 x RJ45 LAN ports
  • 1 x RJ45 Dedicated IPMI LAN port
Audio
Not Available
Video
ASPEED AST2400 BMC
LAN
  • Intel X540 Dual-port 10GBase-T
  • Realtek RTL8211E PHY (dedicated IPMI)
SATA / SAS
8 x SAS 12Gb/s via LSI 3108
SCSI
Not Available
USB Port (s)
  • 2 x USB 3.0 on Back Panel I/O
  • 2 x USB 2.0 on Back Panel I/O
  • 1 x Type A
Floppy Disk Drive
Not Included
Optical Drive(s)
Not Included
Ext. Drive Bays
    36 x 3.5" Hot-swap SAS3 HDD bays:
    • 24 front
    • 12 rear
Int. Drive Bays
Internal Drive Bracket suppports 2x 2.5" devices (Not Included)
Power
1280W High-Efficiency (95%+) power supply
Motherboard Manufacturer
Super X10DRH-iT
Manageability
IPMI 2.0 / KVM over LAN / Media over LAN

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.
