Seasonic Vertex GX-850 850W 80+ Gold ATX 3.0 Power Supply - Fully Modular

Seasonic Vertex GX-850 850W 80+ Gold ATX 3.0 Power Supply - Fully Modular - (Discontinued)

Support: 626 969-9966

Seasonic Vertex GX-850 850W 80+ Gold ATX 3.0 Power Supply - Fully Modular - (Discontinued)

SKU:

992-82134

Fully Compatible With Intel PSDG ATX 3.0 Specifications
12VHPWR Cable for PCIe Gen 5 Graphics card Included
1 x 12+4 Pin 12VHPWR PCI-E Connector
3 x 6+2 pin PCI-E Connectors
10-year Warranty / MTBF: 150,000 hours

Our Price:	Login to see price
Discontinued	- Not orderable

What's New

: Asus Prime RTX 5070 TI 16GB GDDR7 OC PCIe 5.0 Video Card

: Gigabyte B850 AORUS ELITE WIFI7 AMD B850 AM5 ATX Motherboard

: WD Red SN700 PCIe 3.0 x4 NVMe M.2 2280 SSD - 2TB

The Seasonic VERTEX GX-850 provide 850W of true power in Gold levels of efficiency, with all the best features you can expect from a Seasonic power supply:

Fully compatible with ATX 3.0 and PCIe 5.0 standards
Full modularity for the best cable management options:
Added 12VHPWR cable to comply with the new graphic cards
135mm Fluid Dynamic Bearing (FDB) fan for quiet operation
Seasonic Hybrid Silent Fan Control for optimal cooling
Complete protection features: OPP / OVP / UVP / SCP / OCP / OTP
10 years warranty - our commitment to high quality

Description

The Seasonic VERTEX GX-850 provide 850W of true power in Gold levels of efficiency, with all the best features you can expect from a Seasonic power supply:

Fully compatible with ATX 3.0 and PCIe 5.0 standards
Full modularity for the best cable management options:
Added 12VHPWR cable to comply with the new graphic cards
135mm Fluid Dynamic Bearing (FDB) fan for quiet operation
Seasonic Hybrid Silent Fan Control for optimal cooling
Complete protection features: OPP / OVP / UVP / SCP / OCP / OTP
10 years warranty - our commitment to high quality

Specifications

Efficiency

90% at 50% Load

Fans

135mm

MTBF

150,000 hours

Protection

OPP / OVP / UVP / SCP / OCP / OTP

Version Support

ATX 12V / EPS12V

Current

15 - 7.5 A

Frequency

50 Hz - 60 Hz

Output Power

Output Voltage	Output Current
+3.3V	20A
+5V	20A
+12V	70A
-12V	0.3A
+5VSB	3A

Output Voltage

850W

Input Voltage

100V - 240V

Connectors

1 x 20+4-Pin ATX Motherboard
2 x 4+4-Pin EPS CPU
3 x 6+2-Pin PCIe
18 x SATA
3 x Peripheral (4P)
1 x 16-Pin PCIe (12VHPWR)

Dimensions

160mm x 150mm x 86mm

Certifications & Standards

80 PLUS Gold

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

Warranty Length: 10 years
Warranty Provider: Seasonic
Service Contact:
1. First 30-day from invoice date: Allstarshop On-line RMA Request
  This item is returnable for replacement only. It can only be exchanged with the same item.
2. After 30-day from invoice date: Contact Seasonic at 626 969-9966 Or visit Seasonic customer service online.
Technical Support: Seasonic 626 969-9966 or visit Seasonic technical support online.

Package Contents

Seasonic Vertex GX-1000 Power Supply
1 x MB (24/20 pins) 610mm cable
2 x CPU (8/4 pins) 650mm cable
3 x PCIe (8/6 pins) 750mm cable
4 x SATA 950mm cable
1 x SATA 3.3 550mm cable
2 x Molex 690mm cable
1 x 12VHPWR (16 Pins to 16 Pins) 750mm cable
