MSI PRO Z790-P WIFI Z790 LGA1700 ATX Motherboard

Welcome to Allstarshop

This website uses cookies to provide you a personalized web experience. Using this website you agree to our use of cookies. If you require more information, please visit our Privacy Policy. Agree

MSI PRO Z790-P WIFI Z790 LGA1700 ATX Motherboard

Support: (626) 913-0828

MSI PRO Z790-P WIFI Z790 LGA1700 ATX Motherboard

SKU:	800-14061E

Integrated Intel Graphics - HDMI / DisplayPort
Max 128GB / 5x DDR4 DIMM / Up to 7200+(O.C.)
6x SATA 6Gb/s, 4x M.2 / RAID 0, 1, 5, 10
3x USB 3.2 G2 (2x USB-C), 6 x USB 3.2 G1, 8 x USB 2.0
1x PCIe 5.0 x16, 1x PCIe 4.0 x16, 1x PCIe 3.0 x16, 1x PCIe x1

Our Price:	Login to see price
Availability:	Usually ships within 1-2 business days

Accessories

: Intel Core i5-13600K 14-Core LGA1700 w/24MB cache CPU (BOX)

: Intel Core i7-13700K 16-Core LGA1700 w/30MB cache CPU (BOX)

: Intel Core i9-13900K 24-Core LGA1700 w/36MB cache CPU (BOX)

The PRO Z790-P WIFI is perfect for both daily users and performance enthusiasts and is filled with the latest technologies including PCIe 5.0, DDR4 support, 4x M.2 slots (PCIe 4.0 x4), lightning 20G USB connectivity, Core & Memory boosts, extended heatsink design, M.2 thermal solution, Ez debug, Frozr AI cooling and a fully comprehensive rear I/O.

Description

Specifications

CPU Support

LGA1700 socket for 14th, 13th & 12th Generation Intel Core Processors

Number of Processor (s)

Single (Not Included)

Chipset

Intel Z790 chipset

System Bios

UEFI AMI BIOS

Video card slot

PCIe 5.0 x16

Number of Memory Slots

Type of Memory Supported

DDR5-7200+(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600 / 5400 / 5200/ 5000/ 4800MHz Non-ECC, Un-buffered Memory

Maximum RAM

128GB

Back Panel I/O

1 x PS/2 Keyboard/Mouse combo
1x USB 3.2 Gen 2x2 Type-C port
1x USB 3.2 Gen2 Type-A port
2x USB 3.2 Gen1 Type-A ports
4x USB 2.0
1 x HDMI
1 x DisplayPort
1 x RJ45 LAN
1 x Audio I/O
2 x Antenna connectors

Number of PCI/PCI-Express Slots

1 x PCIe 5.0 x16
1 x PCIe 4.0 x16 (max x4)
1 x PCIe 3.0 x16 (max x1)
1 x PCIe 3.0 x1

Integrated SATA/SAS

6 x SATA 6Gb/s

# of M.2 Ports

1 x M.2 socket, with M key, type 2242/2260/2280/22110 supports PCIe 4.0 x4 mode
1 x M.2 socket, with M key, type 2242/2260/2280 supports PCIe 4.0 x4 mode
2 x M.2 socket, with M key, type 2242/2260/2280 support PCIe 4.0 x4 & SATA mode

Integrated SATA/SAS RAID

RAID 0, 1, 5, 10

Integrated Audio

Realtek ALC887 7.1 Surround Sound High Definition Audio CODEC

Integrated Video

Integrated Intel Graphics from processor

Integrated LAN

Intel 2.5Gb Ethernet

Integrated Wifi

Intel Wi-Fi 6E & Bluetooth v5.2

USB

1x USB 3.2 Gen 2x2 Type-C port on Back Panel I/O
1x USB 3.2 Gen2 Type-C port via header
1x USB 3.2 Gen2 Type-A port on Back Panel I/O
2x USB 3.2 Gen1 Type-A ports on Back Panel I/O
4x USB 3.2 Gen1 Type-A ports via headers
4x USB 2.0 on Back Panel I/O
4x USB 2.0 via headers

PS/2 Ports

1 x PS/2 Keyboard/Mouse combo

Form Factor

ATX

Dimensions

12" x 9.6"

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

Warranty Length: 3 years
Warranty Provider: MSI
Service Contact:
1. First 30-day from invoice date: Allstarshop On-line RMA Request
  This item is returnable for replacement only. It can only be exchanged with the same item.
2. After 30-day from invoice date: Contact MSI at (626) 913-0828 Or visit MSI customer service online.
Technical Support: MSI (626) 913-0828 or visit MSI technical support online.
