SKU: 800-28038A
  • Max 3TB / 24 Dimm DDR4 2133/1866/1600MHz ECC Registered
  • 10x SATA 6Gb/s / RAID 0, 1, 10
  • Up to 3x USB 3.0, 5x USB 2.0
  • Intel I350 1Gb Ethernet Controller
Our Price: $499.95
List Price: $736.25 You save: $236.30
Discontinued - Not orderable


Specifications

CPU Support
Intel Xeon processor E5-2600 v3
Number of Processor (s)
Dual (Not Included)
Chipset
Intel C612
Number of Memory Slots
24
Type of Memory Supported
    288-pin DDR4 2133/1600MHz ECC LRDIMM
      or
    288-pin DDR4 2133/1866/1600MHz ECC RDIMM
Maximum RAM
3072 GB
Back Panel I/O
  • 3 x USB 3.0/2.0
  • 1 x VGA
  • 1 x RJ-45 Serial port
  • 2 x RJ45 LAN
  • 1 x RJ45 server management port
Number of PCI/PCI-Express Slots
  • 2 x PCIe 3.0 x24 Riser slots
  • 1 x PCIe 3.0 x8 Riser slots
On-Board EIDE/Floppy
N/A
Integrated SATA/SAS
10 x SATA 6Gb/s
Integrated SATA/SAS RAID
SW RAID 0, 1, 10, optional 5
Integrated Audio
No
Integrated Video
Integrated 2D Video Controller
Integrated LAN
Intel I350 Gb Ethernet Controller
IPMI
Yes
USB
    Up to 8 x USB
    • 3 x USB 3.0 on Back Panel I/O
    • 2 x USB 3.0 ports via headers
    • 2 x USB 2.0 ports via headers
    • 1 x Type A
IEEE 1394
N/A
Serial/Parallel Ports
1 x Serial port via header
PS/2 Ports
N/A
Form Factor
Custom
Dimensions
16.7" x 17"

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

  • Warranty Length: 3 years
  • Warranty Provider: Intel
  • Service Contact:
    1. First 30-day from invoice date: Allstarshop On-line RMA Request
    2. After 30-day from invoice date: Contact Intel at (800) 538-3373
  • Technical Support: Intel (800) 538-3373
