Type

Personal computer

Recommended Use

Small business, corporate business

Product Form Factor

Small form factor

Built-in Devices

Solenoid hood lock

Embedded Security

Trusted Platform Module (TPM 1.2) Security Chip

Localization

English / United States

Processor / Chipset

CPU

AMD A series A4-6300B / 3.7 GHz

Max Turbo Speed

3.9 GHz

Number of Cores

Dual-Core

CPU Qty

1

Max CPU Qty

1

CPU Upgradability

Upgradable

Chipset Type

AMD A75

Cache Memory

Installed Size

L2 cache - 1 MB

Cache Per Processor

1 MB

RAM

Installed Size

4 GB / 32 GB (max)

Technology

DDR3 SDRAM - non-ECC

Form Factor

DIMM 240-pin

Features

Unbuffered

Configuration Features

1 x 4 GB

Hard Drive

Type

HDD

Capacity

1 x 500 GB

Interface Type

SATA 6Gb/s

Spindle Speed

7200 rpm

Storage Controller

Type

1 x SATA - integrated

Controller Interface Type

SATA 6Gb/s

Optical Storage

Type

DVD±RW (±R DL) / DVD-RAM - SATA

Monitor

Monitor Type

None.

Graphics Controller

Type

Integrated

Graphics Processor

AMD Radeon HD 7480D

Video Interfaces

VGA, DisplayPort

Audio Output

Type

Integrated

Compliant Standards

SRS Premium Sound, High Definition Audio

Input Device

Type

Mouse, keyboard

Networking

Type

Integrated

Interface (Bus) Type

PCI Express

Ethernet Controller

Broadcom BCM5761

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet

Remote Management Protocol

DMI 2.0, ASF 2.0

Features

Wake on LAN (WoL), ACPI support, PXE support

Compliant Standards

IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x

Expansion / Connectivity

Bays

1 (total) / 0 (free) x external 5.25" x 1/2H
1 (total) / 1 (free) x external 3.5" x 1/3H
1 (total) / 0 (free) x internal 3.5" x 1/3H

Slots

4 (total) / 3 (free) x DIMM 240-pin
1 (total) / 0 (free) x CPU
1 (total) / 1 (free) x PCI - low-profile
1 (total) / 1 (free) x PCIe 2.0 x1 - low-profile
1 (total) / 1 (free) x PCIe 3.0 x16 - low-profile
1 (total) / 1 (free) x PCIe x16 - low-profile ( x4 mode )

Interfaces

4 x USB 3.0
6 x USB 2.0 ( 4 front, 2 rear )
1 x serial
1 x PS/2 keyboard
1 x PS/2 mouse
1 x VGA
1 x DisplayPort
1 x microphone ( 1 in front )
1 x headphones ( 1 in front )
1 x audio line-in
1 x audio line-out
1 x LAN (Gigabit Ethernet)

Miscellaneous

Features

Security lock slot (cable lock sold separately), system password, power-on password, serial port I/O control, USB port control, active Power Factor Correction (PFC), padlock loop, 90% efficiency power supply

Manufacturer Selling Program

HP Smart Buy

Power

Device Type

Power supply

Nominal Voltage

AC 120/230 V ( 50/60 Hz )

Power Provided

240 Watt

Operating System / Software

OS Provided

Microsoft Windows 7 Professional 64-bit Edition / Windows 8.1 Pro downgrade

Preinstalled OS

Windows 7

OS Certified

SUSE Linux Enterprise Desktop 11

Software

HP ProtectTools Security Manager, Adobe Flash Player, HP Help and Support, Microsoft Security Essentials, HP Recovery Manager, HP Support Assistant, Bing Toolbar, PDF Complete Corporate Edition, Credential Manager for HP ProtectTools, WinZip Basic, Windows 7 Professional 32-bit recovery DVD, HP Marketplace, HP Wallpaper, HP Setup 9.0, HP Spare Key, Password Manager, Box.net 10GB storage, SRS Premium Sound, Windows 8 Pro 64-bit recovery DVD, File Sanitizer for HP ProtectTools, One Step Logon, DigitalPass, Privacy Manager, HP Client Security, HP EUDI Support Environment, Device Access Manager with Just In Time Authentication

Environmental Standards

EPEAT Compliant

EPEAT Gold

ENERGY STAR Qualified

Yes

Manufacturer Warranty

Service & Support

3 years warranty

Service & Support Details

Limited warranty - parts and labor - 3 years - on-site

Dimensions & Weight

Depth

14.9 in

Height

3.9 in

Weight

16.8 lbs

Environmental Parameters

Min Operating Temperature

50 °F

Max Operating Temperature

95 °F

Humidity Range Operating

10 - 90% (non-condensing)
