SKU: 800-26520F
  • Integrated Intel Graphics - HDMI
  • Max 128GB / 4x DDR4 DIMM / Up to 4800 (O.C.)
  • 4x SATA 6Gb/s, 2x M.2 / RAID 0, 1, 5, 10
  • 2x USB 3.2 G2 (1x USB-C), 8x USB 3.2 G1, 4x USB 2.0
  • 1x PCIe 4.0 x16, 1x PCIe 3.0 x16, 1x PCIe x1
Our Price: Login to see price
Discontinued - Not orderable


Specifications

CPU Support
LGA1700 socket for 14th, 13th & 12th Generation Intel Core Processors
Number of Processor (s)
Single (Not Included)
Chipset
Intel Z690 chipset
System Bios
UEFI AMI BIOS
Video card slot
PCIe 4.0 x16
Number of Memory Slots
4
Type of Memory Supported
DDR4-4800(O.C) / 4700(O.C) / 4600(O.C) / 4500(O.C) / 4400(OC) / 4266(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 non-ECC, un-buffered memory
Maximum RAM
128GB
Back Panel I/O
  • 2 x USB 3.2 Gen 2 Type-A ports
  • 4 x USB 3.2 Gen 1 Type-A ports
  • 1 x HDMI
  • 1 x RJ45 LAN
  • 1 x Audio I/O
Number of PCI/PCI-Express Slots
  • 1 x PCIe 4.0 x16
  • 1 x PCIe 3.0 x16 (max x4)
  • 1 x PCIe 3.0 x1
    • Integrated SATA/SAS
    4 x SATA 6Gb/s
    # of M.2 Ports
    • 1 x M.2 socket, with M key, type 2260/2280 support PCIe 4.0 x4 mode
    • 1 x M.2 socket, with M key, type 2280 support PCIe 4.0 x4 & SATA mode
    Integrated SATA/SAS RAID
    RAID 0, 1, 5, 10
    Integrated Audio
    Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC
    Integrated Video
    Integrated Intel Graphics from processor
    Integrated LAN
    Intel I219V Gigabit Ethernet
    USB
    • 2 x USB 3.2 Gen 2 Type-A ports on Back Panel I/O
    • 4 x USB 3.2 Gen 1 Type-A ports on Back Panel I/O
    • 4 x USB 3.2 Gen 1 Type-A ports via headers
    • 4 x USB 2.0 ports via headers
    Form Factor
    Micro ATX
    Dimensions
    9.6" x 9.6"

    The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

    Warranty and Service

    • Warranty Length: 1 year
    • Warranty Provider: Asrock
    • Service Contact:
      1. First 30-day from invoice date: Allstarshop On-line RMA Request
      2. After 30-day from invoice date: Contact Asrock at (909) 590-8308
    • Technical Support: Asrock (909) 590-8308

    Package Contents

    • ASRock Z690 Phantom Gaming 4 motherboard
    • User Guide
    • Support CD
    • 2 x SATA cable
    • 3 x M.2 Screws
