SKU: 800-26501H
  • Integrated Radeon Graphics - HDMI / DisplayPort
  • Max 128GB / 4x DDR5 DIMM / Up to 6000+ (O.C.)
  • 4x SATA 6GB/s, 3x M.2 / RAID 0, 1, 10
  • 7x USB 3.2 G1 (2x USB-C), 8x USB 2.0
  • 1x PCIe 4.0 x16
Our Price: Login to see price
Availability: Temporarily out of stock


Specifications

CPU Support
AMD Ryzen 7000 series processors
Number of Processor (s)
Single (Not Included)
Chipset
AMD A620
System Bios
UEFI AMI BIOS
Video card slot
PCIe 4.0 x16
Number of Memory Slots
4
Type of Memory Supported
DDR5 6000(OC)+ / 5800(OC) / 5600(OC) / 5400(OC) / 5200 / 5000 / 4800 ECC and Non-ECC, Un-buffered Memory
Maximum RAM
128GB
Back Panel I/O
  • 3 x USB 3.2 Gen1 Type-A ports
  • 1 x USB 3.2 Gen1 Type-C port
  • 4 x USB 2.0
  • 1 x DisplayPort
  • 1 x HDMI
  • 1 x RJ45 LAN
  • 1 x Audio I/O
Number of PCI/PCI-Express Slots
1 x PCIe 4.0 x16
Integrated SATA/SAS
4 x SATA 6Gb/s
# of M.2 Ports
  • 2 x M.2 socket, with M key, type 2260/2280 support PCIe 4.0 x4 mode
  • 1 x M.2 socket, with M key, type 2260/2280 support PCIe 3.0 x2 mode
Integrated SATA/SAS RAID
RAID 0, 1, 10
Integrated Audio
Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC
Integrated Video
Integrated Graphics from processor (Actual support may vary by CPU)
Integrated LAN
Realtek 8111H Gigabit Ethernet
USB
  • 3 x USB 3.2 Gen1 Type-A ports on Back Panel I/O
  • 2 x USB 3.2 Gen1 Type-A ports via header
  • 1 x USB 3.2 Gen1 Type-C port on Back Panel I/O
  • 1 x USB 3.2 Gen1 Type-C port via header
  • 4 x USB 2.0 on Back Panel I/O
  • 4 x USB 2.0 via headers
Form Factor
Micro ATX
Dimensions
9.6" x 9.6"

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

  • Warranty Length: 1 year
  • Warranty Provider: Asrock
  • Service Contact:
    1. First 30-day from invoice date: Allstarshop On-line RMA Request
    2. After 30-day from invoice date: Contact Asrock at (909) 590-8308
  • Technical Support: Asrock (909) 590-8308

Package Contents

  • ASRock A620M Pro RS motherboard
  • User Manual
  • 2 x SATA cables
  • 4 x Screws for M.2 Sockets
  • 1 x Standoff for M.2 Socket
