Zalman products have always stood out from the other heatsink manufacturers in performance and appeal. Their long line of quality coolers have been heralded by case modders and overclockers for sometime as quality performers without the associated noise levels. Zalman, ever striding for a completely noiseless system, continuously introduces new products such as coolers for the graphic chip, power supply, and of course, the CPU.

Specification:

• Heatsink Dimension: 95~110 (L) x 52 (W) x 65 (H) mm


• Dissipation Area: 2000 cm2


• Base Material: Pure Copper + Pure Aluminum


• Fan Dimension: 92 (L) x 92 (H) x 25 (W) mm


• Rotational Speed: 1450 RPM +/- 10% (Silent) / 2800 RPM +/- 10% (Normal)


• Noise Level: 20 dBA +/- 10% (Silent) / 35 dBA +/- 10% (Normal)


• Bearing Type: 2-Ball

Supported CPU:

• AMD Duron: All Speeds


• AMD Athlon up to 1.4GHz


• AMD Athlon XP up to XP2600+

For an interactive installation guide, please visit ZALMAN at:

http://www.zalman.co.kr/usa/product/productall/install-plus.htm
