SKU: 800-10229
  • Supports Dual AMD Opteron processors
  • Supports RAID0, 1, 0+1 for storage reliablity
Our Price: Login to see price
Discontinued - Not orderable


Specifications

CPU Support
Supports AMD Opteron processors Socket 940
Number of Processor (s)
Dual (Not Included)
Chipset
  • AMD-8151 AGP 3.0 Graphics Tunnel
  • AMD-8111 HyperTransport I/O Hub
  • Winbond W83627HF Super I/O ASIC
System Bios
AMI BIOS 8.0 on 4Mbit LPC Flash ROM
Video card slot
AGP 8X / 4X
Number of Memory Slots
4
Type of Memory Supported
184-pin DDR 400 / 333 / 266 registered ECC SDRAM
Maximum RAM
8GB
Back Panel I/O
  • 1 x PS/2 Mouse
  • 1 x PS/2 Keyboard
  • 4 x USB 2.0 ports
  • 1 x Serial port
  • 1 x Parallel port
  • 1 x IEEE 1394a port
  • 1 x RJ45 LAN port
  • 3 x Audio jacks
Number of PCI/PCI Express Slots
5
Number of ISA Slots (16 Bit)
No
On-Board EIDE/Floppy
2 x ATA-133 IDE Channel for support up to 4 devices
Integrated IDE RAID
No
Integrated SATA/SAS
    Silicon Image SI3114 controller:
    • Supports up to 4 SATA drives
    • Supports RAID 0, 1, 1+0
Integrated Audio
Realtek ALC655
Integrated Video
No
Integrated LAN
Intel 82541EI GbE LAN controller
Integrated SCSI
No
USB
  • 2 x USB 2.0 ports on Back Panel I/O
IEEE 1394
    Up to 2 IEEE 1394a ports:
    • 1 x IEEE 1394a port on Back Panel I/O
    • 1 x IEEE 1394a port via headers
Form Factor
ATX
Dimensions
12" x 9.8"

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

Package Contents

  • Motherboard
  • 1 x FDD Cable
  • 4 x SATA Cable
  • 2 x SATA Power Cable
  • 2 x CPU Mounting Kits
  • I/O Shield
  • User Manual
  • Setup CD & Driver
