SKU: 850-10215
  • 2x 3rd Gen Intel Xeon Scalable Processors
  • Max 12TB DDR4 3200MHz ECC RDIMM (32 DIMMs)
  • 12x 3.5" SATA bays - hot swap
  • Integrated IPMI 2.0 with KVM and Dedicated LAN
Our Price: Login to see price
Availability: Temporarily out of stock


Specifications

Server Case Form Factor
2U
Processor
  • 3rd Gen Intel Xeon Scalable processors
  • Dual (Not Included)
Chipset
Intel C621A
Type of Memory Supported
DDR4-3200 3DS-RDIMM/3DS-LRDIMM
Maximum Memory Supported
12TB
Number of Memory Slots
32
Slots
  • Riser 1:
    • Supports x32 PCIe lanes, routed from CPU 0
    • PCIe 4.0 support for up to 64 GB/s
  • Riser 2:
    • Supports x32 PCIe lanes, routed from CPU 1
    • PCIe 4.0 support for up to 64 GB/s
  • Riser 3:
    • Supports x16 PCIe lanes, routed from CPU 1
    • PCIe 4.0 support for up to 32 GB/s
Rear I/O Ports
  • 3 x USB 3.0 ports
  • 1 x VGA
  • 1 x RJ45 Remote Management
  • 1 x RJ45 Serial port
Video
Integrated 2D video controller
SATA / SAS
    10 x SATA 6Gb/s:
    • 2 x M.2 -SATA/PCIe
    • 2 x SFF-8643 4-port Mini SAS HD connectors
Ext. Drive Bays
12 x 3.5" SAS/SATA/NVMe hot-swap drive bays
Power
NO PSU included
Motherboard Manufacturer
Intel Server Board M50CYP2SBSTD
Manageability
IPMI 2.0 & Redfish

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

Package Contents

  • 1 x 2U 3.5” Chassis with -Quick Reference Label affixed to top cover
  • 1 x Intel Server Board M50CYP2SBSTD
  • 1 x Front I/O assembly w/ two USB ports, left side
  • 1 x Front control panel (right) with control/status buttons
  • 1 x 2U Hot-swap backplane spare CYPHSBP2312
  • 12 x HDD/SSD drive carriers 3.5"
  • 16 x DIMM Blank
  • 1 x Splitter power cable, server board connector to 3.5" HSBP power connectors, 425/660 mm
  • 1 x I2C cable, server board to- 250 mm
  • 1 x 2U Standard Air duct
  • 6 x 2U Spare Fan Kit CYPFAN2UKIT
  • 2 x Processor carrier clip
