SKU: 455-45025
  • Supports up to 127 USB Devices
  • Switches to the Peripheral’s Highest Supported Speed Automatically
  • Supports all USB speeds
  • 4 x External USB 2.0 Ports / 1 Internal USB 2.0 port
Our Price: Login to see price
Discontinued - Not orderable


Specifications

Device Support
Up to 127 USB
Connectivity Technology
Cable
Data Transfer Rate
  • 480Mbps USB 2.0 High Speed
  • 12Mbps USB 1.1 Full Speed
  • 1.5Mbps USB 1.1 Low Speed
    • Host Interface
    PCI
    Platform Support
  • PC
  • Mac
    • Ports
  • 4 x Type A - USB 2.0 External
  • 1 x Type A - USB 2.0 Internal
    • Humidity
    85% Non-condensing
    Temperature
  • 0 °C (32 °F) to 40 °C (104 °F) Operating
  • -10 °C (14 °F) to 45 °C (113 °F) Storage
    • Weight
    2.4 oz
    Form Factor
    PCI Plug-in Card
    Dimensions
    4.76" Height x 5.2" Width x 0.85" Thickness
    Additional information
  • 32-bit 33Mhz Host Interface Compliant to PCI Specification 2.2
  • Supports PCI-Bus Power Management Interface Specification 1.1
  • Switches to the Peripheral's Highest Supported Speed Automatically
  • Power Consumption: 500mA (max) per port
    • System Requirements
  • Intel Pentium 300MHz or Faster & Mac PCs
  • Windows 98SE/ME/2000/XP or Mac OS X
  • 64MB RAM or More
  • Available PCI Version 2.2 Slot
  • CD-ROM Drive for Driver Installation
    • Compatibility
  • Plug and Play
  • OHCI 1.1
  • EHCI .95

    • Supported Operating System:

  • Windows 98SE
  • Windows ME
  • Windows 2000
  • Windows XP
  • Mac OS X

    • Certifications & Standards
  • FCC
  • CE

    • The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.
