SKU: 850-11774W
  • Per Node: 2x LGA2011-3 E5-2600 v4 / v3 series
  • Per Node: Max 512GB DDR4 2133/1866/1600MHz ECC Reg (8 DIMMs)
  • Per Node: 4x 2.5" SATA bays - Fix - RAID 0, 1, 5, 10
  • Intel i350 Gigabit Ethernet controller
  • Integrated IPMI 2.0 with KVM and Dedicated LAN
Our Price: $1,538.50
List Price: $1,729.00 You save: $190.50
Availability: Temporarily out of stock
  Alert Me | Alternatives?



Specifications

Server Case Form Factor
1U
Processor
  • Intel Xeon processor E5-2600 v4
  • Intel Xeon processor E5-2600 v3
  • Dual (Not Included)
Chipset
Intel C612
Bios
128Mb SPI Flash EEPROM with AMI BIOS
Type of Memory Supported
    288-pin DDR4 2133/1866/1600MHz ECC LRDIMM
      or
    288-pin DDR4 2133/1866/1600MHz ECC RDIMM
Maximum Memory Supported
    Pre Node:
      ECC LRDIMM: 512GB
        or
      ECC RDIMM: 256GB
Number of Memory Slots
8
Slots
    Pre Node:
    • 1 x PCIe 3.0 x16
Rear I/O Ports
    Pre Node:
    • 2 x USB 2.0
    • 1 x VGA
    • 2 x RJ45 Gigabit LAN
    • 1 x RJ45 Dedicated IPMI LAN port
Video
ASPEED AST2400 BMC
LAN
  • Intel i350 Gigabit Ethernet controller
  • IPMI_dedicated LAN support by the ASpeed controller
SATA / SAS
10 x SATA 6Gb/s
USB Port (s)
    Pre Node:
    • 2 x USB 2.0 on Back Panel I/O
Optical Drive(s)
Not Included
Ext. Drive Bays
    Pre Node:
    • 2 x 2.5" Hot-swap drive bays
Int. Drive Bays
Not Available
Power
1000W Titanium Level (96%) High-efficiency AC-DC power supply with PMBus and I2C
Motherboard Manufacturer
Supermicro X10DRT-L
Manageability
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.
