SKU: 850-00G15C
  • Integrated Intel Graphic - HDMI / 2x DisplayPort
  • Max: 64GB / 4 x DDR4-2666
  • 4x USB 3.1 G2, 4x USB 3.1 G1, 4x USB 2.0
Our Price: Login to see price
Discontinued - Not orderable


Specifications

Processor
  • LGA1151 socket for 9th, 8th Generation Intel Core i9 / i7/ i5/ i3 Processors
  • Single (Not Included)
Chipset
Intel H370 chipset
Type of Memory Supported
288-pin DDR4 2666/2400
Installed Memory
0
Maximum Memory Supported
64GB
Number of Memory Slots
4
I/O Ports
    Front:
    • 2 x USB 2.0 ports
    • 2 x USB 3.1 Gen 1 ports
    • 1 x Microphone-In
    Back:
    • 2 x USB 2.0 ports
    • 2 x USB 3.1 Gen 1 ports
    • 4 x USB 3.1 Gen 2 ports
    • 1 x HDMI port
    • 2 x Display port
    • 2 x LAN
Audio
Realtek ALC662 5.1 Channel high definition audio
Video
Integrated Intel Graphics from processor
LAN
Intel i211 Gigabit LAN
Storage
  • 4 x SATA 6Gb/s
  • 1 x M.2 2280 type M key socket
Ext. Drive Bays
1 x 5.25"
Int. Drive Bays
2 x 3.5"
Power
80 Plus 300W power supply
Dimensions
332.1 mm x 215.2 mm x 190 mm (L x W x H)

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

  • Warranty Length: 1 year
  • Warranty Provider: Shuttle
  • Service Contact:
    1. First 30-day from invoice date: Allstarshop On-line RMA Request
    2. After 30-day from invoice date: Contact Shuttle at 626-820-9000
  • Technical Support: Shuttle 626-820-9000

Compatible Accessories

Memory

Kingston 16GB DDR4-2666 CL19 288-pin DIMM
  • PC4-21300
  • Dual-Rank x8
  • DDR4-2666 19-19-19 @ 1.2V
Manufacturer: Kingston
Mfg P/N: KVR26N19D8/16
Availability: Usually ships with 1-2 business days

Hard Drives

WD Black 2TB 7200RPM 64MB Buffer SATA 6Gb/s 3.5" Hard Drive
  • Colossal cache
  • 5-year warranty
Manufacturer: Western Digital
Mfg P/N: WD2003FZEX
Availability: Usually ships with 1-2 business days
WD Blue 1TB 7200RPM 64MB Buffer SATA 6Gb/s 3.5" HDD (Drive Only)
  • 2-year Warranty
Manufacturer: Western Digital
Mfg P/N: WD10EZEX
Availability: Usually ships same day
