SKU: 331-26029
  • Resolution: 1920 x 1080
  • Brightness: 220-250 cd/m2
  • Contrast Ratio: 1000:1
  • Response Time: 14ms
  • 1 x VGA / 1 x HDMI / 1 x DisplayPort / USB 2.0
Our Price: Login to see price
Availability: Temporarily out of stock


Specifications

Viewable Area
23.6" (16:9)
Brightness
  • Touchscreen On: 220 cd/m2
  • Touchscreen Off: 250 cd/m2
  • Contrast Ratio
    1000:1
    Response Time
    14ms
    Viewing Angle
  • Horizontal: 178
  • Vertical: 178
  • Pixel Pitch
    0.2715mm
    Resolution
    1920 x 1080
    Analog Input
    1 x VGA
    Digital Input
    1 x DisplayPort
    HDMI Input
    1 x HDMI
    Built in Speakers
    2 x 1W
    Built-in USB Hub
    2 x USB 2.0
    Power Consumption
  • Normal: 35W
  • Standby: < 1W
  • Dimensions
  • With Stand: 22.5" x 13.7" x 1.8"
  • Without Stand: 22.5" x 13.7" x 1.8"
  • General Information
    Manufacturer
    Planar Systems, Inc
    Manufacturer Part Number
    997-7052-00
    Manufacturer Website Address
    Brand Name
    Planar
    Product Line
    Helium
    Product Model
    PCT2485
    Product Type
    LCD Touchscreen Monitor
    Technical Information
    Screen Size
    24"
    Screen Mode
    Full HD
    Response Time
    14 ms
    Aspect Ratio
    16:9
    Horizontal Viewing Angle
    178°
    Vertical Viewing Angle
    178°
    Adjustable Display Angle
    Yes
    Display Orientation
    Landscape/Portrait
    Mount Type
    Desk Mountable
    Backlight Technology
    LED
    Features
    Security Lock
    Video
    Maximum Resolution
    1920 x 1080
    Standard Refresh Rate
    60 Hz
    Color Supported
    16.7 Million Colors
    Contrast Ratio
    1,000:1
    Brightness
    250 Nit
    Audio
    Speakers
    Yes
    Touchscreen Information
    Touchscreen
    Yes
    Touchscreen Type
    Projected Capacitive
    Multi-touch Screen
    Yes
    Interfaces/Ports
    HDMI
    Yes
    USB
    Yes
    USB Standard
    USB 2.0
    VGA
    Yes
    Headphone
    Yes
    DisplayPort
    Yes
    Built-in Devices
    Built-in Devices
  • Microphone
  • Speaker
  • USB Hub
  • Webcam
  • Power Description
    Input Voltage
  • 110 V AC
  • 220 V AC
  • Operating Power Consumption
    35 W
    Standby Power Consumption
    1 W
    Off-Mode Power Consumption
    1 W
    Physical Characteristics
    VESA Mount Compatible
    Yes
    VESA Mount Standard
    100 x 100
    Color
    Black
    Height
    13.7"
    Width
    20.4"
    Depth
    1.8"
    Miscellaneous
    Certifications & Standards
    • HID
    • UL/c-UL
    • FCC-Class B
    • CE
    • TUV/Bauar
    Platform Supported
    PC
    Green Compliant
    Yes
    Green Compliance Certificate/Authority
    RoHS

    The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

    Warranty and Service

    • Warranty Length: 3 years
    • Warranty Provider: Planar
    • Service Contact:
      1. First 30-day from invoice date: Allstarshop On-line RMA Request
      2. After 30-day from invoice date: Contact Planar at 866-752-6271
    • Technical Support: Planar 866-752-6271

    Package Contents

    • Helium PCT2485 24" Widescreen Multi-Touch Monitor
    • Power Cord
    • VGA Cable
    • HDMI Cable
    • USB Cable (A to B)
    • Audio-in Cable
    • User's Guide
    • Cleaning Cloth
    • Stylus
    • Cable Wrap
