SKU: 331-26008
  • 1920 x 1080 Resolution
  • VGA / DVI / USB / Dual RS-232
  • 1000:1 Contrast Ratio
  • Durable SAW touch screen
  • Recognizes touch input from finger, gloved hand, or soft stylus
Our Price: Login to see price
Discontinued - Not orderable


Specifications

Display Type
LCD display / TFT active matrix
Built-in Devices
Stereo speakers
Depth
11.2 in
Height
15 in
Weight
23.1 lbs
Display
Diagonal Size
22" - widescreen
Viewable Size
21.5"
Max Resolution
1920 x 1080
Response Time
5 ms
Display Positions Adjustments
Tilt
Tilt Angle
95
Signal Input
DVI-D, VGA
Image Aspect Ratio
16:9
Image Brightness
270 cd/m2
Image Contrast Ratio
1000:1
Image Max H-View Angle
170
Image Max V-View Angle
160
Video Input
Analog Video Signal
RGB
Digital Video Standard
Digital Visual Interface (DVI)
Audio Output
Output Power / Channel
2 Watt
Input Device
Type
Touch-screen
Movement Detection Technology
Surface acoustic wave
Expansion / Connectivity
Interfaces
1 x VGA - 15 pin HD D-Sub (HD-15)
1 x DVI-D - 24 pin digital DVI
1 x serial RS-232 - 9 pin D-Sub (DB-9)
1 x USB - 4 pin USB Type B
1 x audio line-in - mini-phone stereo 3.5 mm
Miscellaneous
Cables Included
1 x VGA cable
1 x DVI cable
1 x serial cable
1 x USB cable - USB Type A to B
1 x audio cable
Flat Panel Mount Interface
100 x 100 mm
Compliant Standards
FCC Class B certified, CE, UL, TUV, cUL, RoHS
Power
Form Factor
Internal
Voltage Required
AC 120/230 V ( 50/60 Hz )
Power Consumption Operational
60 Watt
Power Consumption Stand by / Sleep
4 Watt
Software / System Requirements
Software Included
Driver
OS Required
Microsoft Windows 98, Microsoft Windows NT 4.0, Apple MacOS, Microsoft Windows CE, Linux, Microsoft Windows 2000, Microsoft Windows Millennium Edition, Microsoft Windows XP, Microsoft Windows XP Embedded, Microsoft Windows Vista
Manufacturer Warranty
Service & Support
3 years warranty
Service & Support Details
Limited warranty - replacement - 3 years - response time: 2 days

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

  • Warranty Length: 3 years
  • Warranty Provider: Planar
  • Service Contact:
    1. First 30-day from invoice date: Allstarshop On-line RMA Request
    2. After 30-day from invoice date: Contact Planar at 866-752-6271
  • Technical Support: Planar 866-752-6271

Package Contents

  • Touch screen monitor
  • Power cord
  • VGA cable
  • DVI-D cable
  • RS-232 cable
  • USB cable (A to B)
  • Audio-in cable
  • Driver CD
  • User's guide
  • Quick start guide
