  1. Home
  2. Monitors
  3. 15 to 18-inch Monitors
SKU: 330-040101B
  • Resolution: 1280 x 1024
  • Brightness: 250 cd/m2
  • Contrast Ratio: 1000:1
  • Response Time: 5 ms
  • 1 x VGA / 1 x DVI-D
Our Price: Login to see price
Discontinued - Not orderable


Specifications

Viewable Area
17" (5:4)
Brightness
250 cd/m2
Contrast Ratio
1000:1
Response Time
5 ms
Viewing Angle
  • Horizontal: 170
  • Vertical: 170
    • Pixel Pitch
    0.26 mm
    Resolution
    1280 x 1024
    Horizontal Frequency
    31.5-81.1 kHz
    Vertical Frequency
    56-76 Hz
    Analog Input
    1 x VGA
    Digital Input
    1 x DVI-D
    Power Consumption
    11 W
    Dimensions
  • W/ Stand: 14.7 x 14.7 x 8.1 in. / 373.2 x 373.1 x 205.1mm
  • W/o Stand: 14.7 x 12.2 x 2.7 in. / 373.2 x 310.2 x 69mm
    • Wall Mount (VESA)
    100 x 100 mm
    General Information
    Manufacturer
    NEC
    Manufacturer Part Number
    AS172-BK
    Manufacturer Website Address
    www.necdisplay.com
    Brand Name
    NEC Display
    Product Line
    AccuSync
    Product Model
    AS172-BK
    Product Type
    LCD Monitor
    Technical Information
    Number of Screens
    1
    Screen Size
    17"
    Screen Mode
    SXGA
    Panel Technology
    Twisted Nematic Film (TN Film)
    Response Time
    5 ms
    Aspect Ratio
    5:4
    Horizontal Viewing Angle
    170°
    Vertical Viewing Angle
    170°
    Adjustable Display Angle
    Yes
    Mount Type
    Desk Mountable
    Backlight Technology
    LED
    HDCP Supported
    Yes
    Features
  • AccuColor
  • Carbon Footprint Meter
  • Eco Mode
  • Intelligent Power Manager (IPM) System
  • Display Power Management Signaling (DPMS)
  • Sync on Green
    • Video
    Maximum Resolution
    1280 x 1024
    Standard Refresh Rate
    76 Hz
    Contrast Ratio
    1,000:1
    Brightness
    250 Nit
    Interfaces/Ports
    DVI
    Yes
    VGA
    Yes
    Power Description
    Operating Power Consumption
    11 W
    Standby Power Consumption
    150 mW
    Physical Characteristics
    VESA Mount Compatible
    Yes
    VESA Mount Standard
    100 x 100
    Color
    Black
    Height
    12.2"
    Depth
    2.7"
    Height with Stand
    14.70"
    Width with Stand
    14.70"
    Depth with Stand
    8.10"
    Miscellaneous
    Certifications & Standards
    ISO 9241-307 Class I
    Green Compliant
    Yes
    Green Compliance Certificate/Authority
  • ENERGY STAR 6.0
  • RoHS
  • TCO Certified Displays 6.0
  • EPEAT Silver

    • The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

    Warranty and Service

    Package Contents

    • 17" Value Desktop Monitor with LED Backlighting
    • Setup Sheet
    • User Manual
    • Power Cord
    • 15-pin D-sub cable
