SKU: 800-14127H
  • Max 24GB / 6 x Dimm DDR3 1333/1066/800
  • 7 x SATA, 1 x eSATA / RAID 0, 1, 10, 5 / 1 x IDE / 0 x FDD
  • Up to 12 x USB 2.0, 2 x IEEE 1394a
  • 3 x PCI-E 2.0 X16, 2 x PCI-E X1, 2 x PCI
Our Price: Login to see price
Discontinued - Not orderable


Specifications

CPU Support
    LGA1366 socket:
    • Intel Core i7 Extreme
    • Intel Core i7
Number of Processor (s)
Single (Not Included)
Chipset
  • Intel X58
  • Intel ICH10R
Video card slot
PCI-Express 2.0 X16
Number of Memory Slots
6
Type of Memory Supported
240-pin DDR3 1333/1066/800 memory
Maximum RAM
24GB
Back Panel I/O
  • 1 x PS/2 Keyboard
  • 1 x PS/2 mouse
  • 1 x Optical S/PDIF Out
  • 1 x eSATA
  • 6 x USB 2.0 ports
  • 1 x RJ45 LAN port
  • 1 x IEEE 1394 port
  • 1 x Audio I/O
    Number of PCI/PCI-Express Slots
    • 3 x PCI-Express 2.0 X16
    • 2 x PCI-Express X4
    • 2 x PCI
    Number of ISA Slots (16 Bit)
    No
    On-Board EIDE/Floppy
    1 x UltraDMA 100/66/33 channel
    On-Board IDE RAID
    No
    Integrated SATA/SAS
      Intel ICH10R:
      • 6 x SATA II 3.0Gb/s
      JMicron 363:
      • 1 x SATA II 3.0Gb/s
      • 1 x eSATA
    Integrated SATA/SAS RAID
      Intel ICH10R:
      • Supports RAID 0, 1, 5 and 10
    Integrated Audio
    Realtek ALC889 8-channel (7.1) audio codec
    Integrated Video
    No
    Integrated LAN
    Realtek 8111C Gigabit LAN controller
    Integrated SCSI
    No
    USB
      Up to 12 x USB ports:
      • 6 x USB ports on Back Panel I/O
      • 6 x USB ports via headers
    IEEE 1394
      Up to 2 x IEEE 1394 ports:
      • 1 x IEEE 1394 port on Back Panel I/O
      • 1 x IEEE 1394 port via header
    Serial/Parallel Ports
    No
    PS/2 Ports
    • 1 x PS/2 Keyboard
    • 1 x PS/2 mouse
    Form Factor
    ATX
    Dimensions
    12" x 9.6"

    The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.
