SKU: 850-28025C
  • LGA1366 Xeon 5600, 5500 CPU
  • Max 128GB DDR3 800/1066/1333 Reg ECC DIMM (8 DIMMs)
  • 4 x 2.5" or 3.5" SATA/SAS bays - Hot Swap - RAID 0/1/10 - ICH10R
  • Intel 82576 - 2 x Gigabit ports
Our Price: Login to see price
Discontinued - Not orderable


Specifications

Product Form Factor
Rack-mountable - 1U
Server Scalability
2-way
Front Accessible Bays Qty
1
Hot-Swap Bays Qty
4
Depth
26.4 in
Height
1.7 in
Weight
21.8 lbs
Localization
North America
Processor
Upgradability
Upgradable
Mainboard
Chipset Type
Intel 5500
RAM
Installed Size
0 MB / 64 GB (max)
Technology
DDR3 SDRAM - ECC
Form Factor
DIMM 240-pin
Features
Unbuffered, registered
Storage Controller
Controller Interface Type
Serial ATA-300
Channel Qty
6
RAID Level
RAID 0, RAID 1, RAID 10
Monitor
Monitor Type
None.
Graphics Controller
Type
Integrated
Graphics Processor / Vendor
ServerEngines Pilot II
Video Memory
64 MB DDR2 SDRAM
Networking
Networking
Network adapter
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller(s)
Intel 82576EB
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
IPMI 2.0
Remote Management Controller
Intel Baseboard Management Controller (BMC)
Expansion / Connectivity
Expansion Bays Total (Free)
4 ( 4 ) x hot-swap - 3.5"
1 ( 1 ) x front accessible - 5.25" Slim Line
Expansion Slots Total (Free)
2 ( 2 ) x processor - LGA1366 Socket
8 ( 8 ) x memory - DIMM 240-pin
1 ( 1 ) x PCI Express 2.0 x8
Interfaces
2 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45
1 x display / video - VGA - 15 pin HD D-Sub (HD-15)
1 x serial - RJ-45
6 x Hi-Speed USB - 4 pin USB Type A ( 2 front, 4 rear )
Miscellaneous
Included Accessories
Rack mounting kit, PCI Express riser card, 2 x CPU Heatsink
Compliant Standards
RoHS, 80 PLUS Silver
Power
Device Type
Power supply
Power Redundancy
Yes
Power Redundancy Scheme
1+1
Installed Qty
2
Max Supported Qty
2
Power Provided
450 Watt
Environmental Standards
ENERGY STAR Qualified
Yes
Manufacturer Warranty
Service & Support
3 years warranty
Service & Support Details
Limited warranty - 3 years

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

  • Warranty Length: 3 years
  • Warranty Provider: Intel
  • Service Contact: Intel (800) 538-3373
  • Technical Support: Intel (800) 538-3373
