SKU: 800-51175E
  • Integrated Radeon Graphics - 2x USB4-C
  • Max 128GB / 4x DDR5 DIMM / Up to 6400+ (O.C.)
  • 6x SATA 6GB/s, 5x M.2 / RAID 0, 1, 10
  • Up to 2x USB4-C, 12x USB 3.2 G2 (4x USB-C), 4x USB 3.2 G1, 2x USB 2.0
  • 2x PCIe 5.0 x16, 1x PCIe 4.0 x4
Our Price: Login to see price
Discontinued - Not orderable


Specifications

CPU Support
AMD Ryzen 7000 series processors
Number of Processor (s)
Single (Not Included)
Chipset
AMD X670E
System Bios
UEFI AMI BIOS
Video card slot
PCIe 5.0 x16
Number of Memory Slots
4
Type of Memory Supported
DDR5-6400+(OC) / 6200(OC) / 6000(OC) / 5800(OC) / 5600(OC) / 5400(OC) / 5200 / 5000 / 4800, ECC and Non-ECC, Un-buffered Memory
Maximum RAM
128GB
Back Panel I/O
  • 2 x USB4 Type-C ports
  • 1 x USB 3.2 Gen 2x2 Type-C port
  • 1 x USB 3.2 Gen2 Type-C port
  • 8 x USB 3.2 Gen2 Type-A ports
  • 2 x RJ45 LAN
  • 1 x Audio I/O
  • 2 x Antenna connectors
Number of PCI/PCI-Express Slots
  • 2 x PCIe 5.0 x16 (Single x16, dual x8/x8)
  • 1 x PCIe 4.0 x4
Integrated SATA/SAS
6 x SATA 6Gb/s
Graphics
Integrated Graphics from processor (Actual support may vary by CPU)
# of M.2 Ports
  • 2 x M.2 socket, with M key, type 2242/2260/2280 support PCIe 5.0 x4
  • 1 x GEN-Z M.2 2242/2260/2280/22110 supports PCIe 5.0 x4 mode
  • 1 x PCIe 5.0 M.2 card 2242/2260/2280/22110 supports PCIe 5.0 x4 mode
  • 1 x GEN-Z.2_2 supports PCIe 4.0 x4 mode
Integrated SATA/SAS RAID
RAID 0, 1, 10
Integrated Audio
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC
Integrated Video
Integrated Graphics from processor (Actual support may vary by CPU)
Integrated LAN
  • Intel 2.5 Gb Ethernet
  • Marvell 10 Gb Ethernet
Integrated Wifi
2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) & Bluetooth v5.3
USB
  • 2 x USB4 Type-C ports on Back Panel I/O
  • 1 x USB 3.2 Gen 2x2 Type-C port on Back Panel I/O
  • 1 x USB 3.2 Gen 2x2 Type-C port via header
  • 1 x USB 3.2 Gen2 Type-C port on Back Panel I/O
  • 1 x USB 3.2 Gen2 Type-C port via header
  • 8 x USB 3.2 Gen2 Type-A ports on Back Panel I/O
  • 4 x USB 3.2 Gen1 Type-A ports via headers
  • 4 x USB 2.0 via headers
Form Factor
E-ATX
Dimensions
12" x 10.9"

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.
