SKU: 800-51114C
  • Supports Dual-Core AMD Opteron 2000 Series processor
  • Supports SLI technology
Our Price: Login to see price
Discontinued - Not orderable


Specifications

CPU Support
  • Dual 1207-pin Socket F
  • Supports Dual-Core AMD Opteron 2000 Series processor
Number of Processor (s)
Dual (Not Included)
Chipset
nVIDIA MCP55 Professional
Video card slot
PCI-Express X16
Number of Memory Slots
8
Type of Memory Supported
240-pin DDR2 667/533 registered ECC SDRAM
Maximum RAM
32GB
Back Panel I/O
  • 1 x PS/2 Keyboard
  • 1 x PS/2 Mouse
  • 1 x Serial port
  • 1 x Parallel port
  • 2 x RJ45 LAN ports
  • 4 x USB ports
  • 1 x Audio I/O
  • 1 x Optical S/PDIF out
  • 1 x Coaxial S/PDIF out
Number of PCI/PCI Express Slots
  • 2 x PCI-Express X16
  • 1 x PCI-Express X1
  • 1 x PCI
Number of ISA Slots (16 Bit)
No
On-Board EIDE/Floppy
2 x UltraDMA 133/100/66/33 channels
Integrated IDE RAID
No
Integrated SATA/SAS
    MCP55 Pro:
    • 6 x SATA 3GB/s
    Sil3132:
    • 2 x SATA 3GB/s
Integrated SATA/SAS RAID
    MCP55 Pro:
    • Supports RAID 0, 1, 0+1, 5 and JBOD
    Sil3132:
    • Supports RAID 0, 1
Integrated Audio
Realtek ALC880 8-channel CODE
Integrated Video
No
Integrated LAN
2 x Broadcom BCM5754 PCI-E Gigabit Ethernet controller
Integrated SCSI
No
USB
    Up to 10 USB ports:
    • 4 x USB ports on Back Panel I/O
    • 6 x USB ports via headers
Form Factor
eATX
Dimensions
12" x 10.5"

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

Package Contents

  • 1 x Motherboard
  • 4 x SATA cable
  • 2 x SATA power cable
  • 1 x IDE cable
  • 1 x FDD cable
  • 1 x I/O Shield
  • Setup CD
  • User's manual
