SKU: 992-16134B
  • 80%+ efficiency / 80 plus Certified / nVidia SLI Certified
  • 4 x +12V rails
  • 2 x 6-pin PCI-E & 2 x 6+2-pin PCI-E connectors
  • ATX12V v2.3 / EPS12V v2.91
  • 5-year warranty
Our Price: Login to see price
Discontinued - Not orderable


Specifications

Efficiency
82%
Protection
  • Over Voltage Protection
  • Under Current Protection
  • Short Circuit Protection
  • Over Power Protection
  • Over Current Protection
Version Support
ATX 12V v2.3 & EPS12V v2.91
Current
  • 10A @ 115VAC
  • 5A @ 230VAC
Frequency
47Hz ~ 63Hz
Output Voltage
Output VoltageMin. LoadMax. LoadRegulationNoise
+3.3V0A25A5%50mV
+5V0A25A5%50mV
+12V10A25A3%120mV
+12V20A25A3%120mV
+12V30A25A3%120mV
+12V40A25A3%120mV
-12V0A0.8A10%120mV
+5Vsb0A3A5%50mV
Input Voltage
AC 115/230 V
Connectors
  • 1 x Main Power Connector (20+4Pin)
  • 1 x 4 Pin ATX12V
  • 1 x 8Pin EPS 12V
  • 2 x PCI-E 8pin (6+2pin)
  • 2 x PCI-E 6pin
  • 9 x SATA
  • 9 x Peripheral
  • 1 x FDD
Specification Compliance
ATX12V 2.3/ EPS12V 2.91
Depth
5.9 in
Height
3.4 in
Weight
5.1 lbs
Localization
United States
Power Device
Frequency Required
47 - 63 Hz
Input Connector(s)
1
Output connector(s)
8 pin PCI Express power with detachable 2 pin section
Power Output Connectors Details
4 x 8 pin PCI Express power with detachable 2 pin section
Power Provided
750 Watt
Miscellaneous
Features
Overcurrent protection, overvoltage protection, overpower protection, SLI ready, cable management, 120mm blue LED cooling fan, short-circuit protection
Compliant Standards
FCC Class B certified, CE, UL, TUV, C-Tick, BSMI, cUL, CB, CCC, RoHS

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.
