SKU: 992-16132G
  • 80%+ efficiency / 80 plus Certified / nVidia SLI Certified
  • 4 x +12V rails
  • 2 x 6-pin PCI-E & 2 x 6+2-pin PCI-E connectors
  • ATX12V v2.3 / EPS12V v2.91
  • 5-year warranty
Our Price: Login to see price
Discontinued - Not orderable


Specifications

Specification Compliance
ATX12V 2.3/ EPS12V 2.91
Depth
5.9 in
Height
3.4 in
Weight
5.1 lbs
Localization
United States
Frequency Required
47 - 63 Hz
Input Connector(s)
1
Output Voltage
+3.3, +5, ±12 V
Input Voltage
AC 115/230 V
Output connector(s)
8 pin PCI Express power with detachable 2 pin section
Power Output Connectors Details
2 x 8 pin PCI Express power with detachable 2 pin section
Power Provided
650 Watt
Output Current
+5V - 25 A / 0 A
+3.3V - 25 A / 0 A
+12V1 - 22 A / 0 A
+12V2 - 22 A / 0 A
+12V3 - 25 A / 0 A
+12V4 - 25 A / 0 A
-12V - 0.8 A / 0 A
+5VSB - 3 A / 0 A
Features
120mm fan, overcurrent protection, overvoltage protection, overpower protection, SLI ready, cable management, short-circuit protection
Compliant Standards
FCC Class B certified, CE, UL, TUV, C-Tick, BSMI, cUL, CB, CCC, RoHS
Service & Support Details
Limited warranty - parts and labor - 5 years

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.
