SKU: 992-16165B
  • Efficiency up to 92%
  • 1 x +12V Rail
  • 1x 8-pin 12V
  • 4 x 6+2-pin PCI-E
Our Price: Login to see price
Discontinued - Not orderable


Specifications

Efficiency
Up to 92%
Fans
1 x 120mm
Protection
OCP/OVP/UVP/SCP/OPP/NLO
Version Support
ATX-12V 2.4
Current
8A-4A
Frequency
50Hz-60Hz
Output Power
600W
Output Voltage
Output VoltageOutput Current
+3.3V18A
+5V18A
+12V150A
-12V0.3A
+5Vsb2.5A
Input Voltage
100-240 VAC
Connectors
  • 1 x 24-Pin Main Power
  • 1 x 4+4-pin ATX12V
  • 4x 6+2-pin PCI-E
  • 2 x Molex
  • 6 x SATA
Dimensions
140(L) x 150(W) x 86(H) mm
Certifications & Standards
  • 80 PLUS Gold
  • cTUVus/TUV/CB/RCM/CE/CCC/BSMI/FCC/KC
  • The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

    Warranty and Service

    Package Contents

    • Power Supply
    • Power Cord
