SKU: 992-16123
  • 85%+ efficiency / 80 plus Certified
  • 2 x +12V rails
  • 2 x 6-pin PCI-E
  • MTBF: 80,000 hours
  • ATX12V 2.2
  • Free Ground Shipping
Our Price: Login to see price
Discontinued - Not orderable


Specifications

Efficiency
85%
Fans
80mm
Holdup Time
20 ms Full-load
MTBF
80000 hours
Protection
  • Over Voltage
  • Under Voltage
  • Short Circuit
  • Over Power
  • Over Temperature
    • Version Support
    ATX 12V Ver. 2.2
    Current
  • 12A @ 115V AC - Input Current
  • 6A @ 230V AC - Input Current
  • 100A @ 230V AC - Inrush - Input Current
  • < 3.5mA @ 115V AC - Leakage -
  • 0.5A to 20A @ 3.3V DC - Input Current
  • 0.5A to 20A @ 5V DC - Input Current
  • 1A to 17A @ 12V DC - V1Input Current
  • 1A to 17A @ 12V DC - V2Input Current
  • 0A to 0.8A @ -12V DC - Input Current
  • 0A to 2.5A @ 5V DC - StandbyInput Current
    • Frequency
  • 50 Hz
  • 60 Hz
    • Output Power
    500 W Maximum
    Output Voltage
    Output VoltageMin. LoadMax. LoadRegulationNoise
    +3.3V0.5A24A+5,-5%50mV
    +5V0.3A24A+5,-5%50mV
    +12V11.0A22A+5,-5%120mV
    +12V21.0A22A+5,-5%120mV
    -12V0A0.8A+10,-10%120mV
    +5Vsb0A2.5A+5,-5%50mV
    Input Voltage
    115V AC to 230V AC
    Interfaces/Ports
  • Logic On/Off Switch
  • Power Rocker Switch
  • Voltage Selector Switch
    • Connectors
  • 2 x 6-pin PCI-E
  • 3-pin TX3 Fan Sensor
  • 1 x 4-pin ATX12V
  • 1 x ATX Motherboard
  • 4 x 15-pin S ATA
  • 2-pin LP4 Fan
    • Weight
    5 lb
    Dimensions
    3.4" Height x 5.9" Width x 6.1" Depth
    Certifications & Standards

  • UL
  • CUL
  • FCC Class B
  • TÜV
  • CE
  • C-tick
  • CCC
  • CB
  • 80 PLUS

    • Compatibility

    Compliance Version:

  • ATX 12V v2.0
  • ATX 12V v2.2

    • The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

    Warranty and Service

    Package Contents

    • 1 x Power Supply
    • 1 x Power Cord
    • 2 x Molex connector w/77cm cable (includes 3 Molex connectors)
    • 1 x 14cm Molex to Floppy connectors w/cable (include 1 Molex and 2 floppy connectors)
    • 1 x 60cm PCI Express adapter

    • 2 x 73cm Serial ATA connector w/cable (includes 2 SATA connectors)
