Antec Atlas Server Case w/550W EPS PSU (Black) - (Discontinued)

Support: (800) 222-6832

Antec Atlas Server Case w/550W EPS PSU (Black) - (Discontinued)

SKU:	990-16159A

Motherboards: ATX, mATX
8 drive bays: Ext - 4 x 5.25", 1 x 3.5" (5.25"-to-3.25") / Int - 4 x 3.5"
Front I/O: 2 x USB, 1 x Firewire, Audio In/Out
Fan: 1 x rear 120mm installed
Trio 550W ATX12V v. 2.2 PSU

Our Price:	Login to see price
Discontinued	- Not orderable

Accessories

: 24-inch SATA Cable

The new, smaller sibling to the Titan 550, the Atlas case continues to meet the needs of today’s server and workstation markets. Front accessible HDD installation, a 120mm TriCool™ exhaust fan & two front 92mm fan mounts and a 550W power supply make building, upgrading and accessing a breeze. An ideal case for professional system builders and power users building a sturdy server.

Output Connectors

20+4-pin Main Power x 1


4-pin Peripheral x 6	4-pin Floppy x 1	SATA x 4	4-pin 12V x 1	6-pin PCI-Express x 2
8-pin 12Vx 1

Description

Output Connectors

20+4-pin Main Power x 1


4-pin Peripheral x 6	4-pin Floppy x 1	SATA x 4	4-pin 12V x 1	6-pin PCI-Express x 2
8-pin 12Vx 1

Specifications

M/B Format

Standard ATX
Micro ATX

Ext. Bay (s)

4 x 5.25" (with one 5.25 to 3.5" adapter)

Int. Bay (s)

4 x 3.5" removable HDD trays with rubber grommets to isolate drive vibrations

Cooling Fan (s)

1 x rear 120 mm TriCool 3-speed fan
2 front mounts for optional 92mm fans
Side Panel vent with mount for optional 80mm fan to provide maximum cooling to the VGA card

Power Supply

Antec TruePower Trio 550W ATX12V ver. 2.2

USB Port (s)

2 x USB 2.0

FireWire Port (s)

1 x IEEE1394

eSATA port

N/A

Audio Port

Audio In/Out

Expansion Slots

Dimensions

17" x 8.1" x 18.5" (H x W x D)

Additional information

Blue LEDs on front for Power On and HD indicators
Removable front bezel for easy access to drive bays
Removable side panel with easy-access thumb screws
2 x USB 2.0
1 x IEEE 1394
Audio In and Out

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

Warranty Length: 3 years
Warranty Provider: Antec
Service Contact:
1. First 30-day from invoice date: Allstarshop On-line RMA Request
  This item is returnable for replacement only. It can only be exchanged with the same item.
2. After 30-day from invoice date: Contact Antec at (800) 222-6832 Or visit Antec customer service online.
Technical Support: Antec (800) 222-6832 or visit Antec technical support online.

Package Contents

1 Tower Case
550W TruePower pre-installed
Power cord
screws and motherboard standoffs
1 complete set of drive rails
1 Installation manual

Compatible Accessories

24-inch SATA Cable

Compatible with both 3.5” and 2.5” Serial ATA devices
24-inch length
Transfer rates up to 6 Gbps (SATA3)

Manufacturer: A-link

Mfg P/N: 91000086B

Availability: Temporarily out of stock
