SKU: 995-12540
  • Maintains 120V nominal output during blackouts
  • Space saving right-angle input plug
  • 3 battery supported outlets
Our Price: Login to see price
Availability: Usually ships within 1-2 business days


Specifications

Plug/Connector Type
NEMA 5-15P
Receptacles
  • 4 x NEMA 5-15R - Backup/Surge-protected
  • 4 x NEMA 5-15R - Surge-protected
    • Switching Time
    4 ms
    Dataline Protection
    RJ-11 Phone/Fax/Modem/DSL
    Load Capacity
    350VA/180W
    Input Voltage
    110V AC
    Input Voltage Range
    120V AC Single-phase
    Output Voltage
    120V AC Single-phase Nominal
    Frequency
    60Hz
    Current
    15A Line mode
    Waveform Type
    Pulse-width Modulated Sine Wave
    Surge Energy Rating
    380J
    Filtering
    EMI/RFI
    Network Management
    Not Applicable
    Alarm
  • On Battery
  • Self-test Operation
    • Status Indicators
  • Line Power
  • Battery Power Status
    • Interfaces/Ports
    1 x USB
    Batteries
    Sealed Lead-acid User-replaceable Hot-swappable
    Backup/Run Time
  • 10 Minute 90W Half-load
  • 3 Minute 180W Full-load
    • Battery Life
    3 Year to 6 Year
    Battery Recharge Time
    4 Hour
    Temperature
  • 32 °F (0 °C) to 104 °F (40 °C) Operating
  • 5 °F (-15 °C) to 122 °F (50 °C) Storage
    • Humidity
    0 to 95% Non-condensing Relative Humidity
    Sound Emission
    >40 dB
    Color
    Black
    Form Factor
    Wall-mountable Ultra-compact Desk-mount
    Power Cord/Cable
    6 ft
    Dimensions
    4" Height x 12" Width x 7" Depth
    Shipping Dimensions
    4.5" Height x 12.5" Width x 7.75" Depth
    Weight
    7.7 lb
    Shipping Weight
    10 lb
    Additional information
  • Line mode BTU/hr. (Max.): 15.7
  • Battery mode BTU/hr. (Max.): 53.2
  • Cold Start: Inverter can be cold started to enable temporary AC output during a power failure
  • Switches: Combination power off / on / self-test push button switch
    • Certifications & Standards
  • UL1778 (USA)
  • cUL (Canada)
  • FCC Class B (emissions)
  • NOM (Mexico)
  • FCC Part 68 / Industry Canada (telecommunications)
  • Conforms to IEEE 587 / ANSI C62.41 specifications
    • Country of Origin
    China

    The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

    Warranty and Service

    • Warranty Length: 2 years
    • Warranty Provider: Tripp Lite
    • Service Contact:
      1. First 30-day from invoice date: Allstarshop On-line RMA Request
      2. After 30-day from invoice date: Contact Tripp Lite at (773) 869-1234
    • Technical Support: Tripp Lite (773) 869-1234

    Package Contents

    • INTERNET350U 350VA UPS
    • USB cable
    • PowerAlert Software
    • Instruction manual with warranty information
