SKU: 992-63135K
  • Fully Compatible With Intel PSDG ATX 3.0 Specifications
  • 12VHPWR Cable for PCIe Gen 5 Graphics card Included
  • 1 x 12+4 Pin 12VHPWR PCI-E Connector / up to 600W
  • 6 x 6+2 pin PCI-E Connectors
  • 10-year Warranty / MTBF: 100,000 hours
Our Price: Login to see price
Availability: Usually ships within 1-2 business days


Specifications

Efficiency
80 PLUS GOLD
Fans
14cm hydraulic bearing fan
MTBF
100,000 hours
Protection
OCP, OVP, UVP, OPP, SCP, OTP
Version Support
ATX 12V / EPS12V
Current
input current: 16A/8A
Frequency
50Hz - 60Hz
Output Voltage
Output VoltageOutput Current
+3.3V24A
+5V24A
+12V1112.5A
-12V0.5A
+5Vsb3A
Input Voltage
100 Vac - 240 Vac
Connectors
  • 1 x Main Power Connector 24 pin
  • 2 x ATX 12V (4+4 Pin)
  • 12 x SATA
  • 6 x PCI-E (6+2 Pin)
  • 1 x 12VHPWR PCI-E (12+4 Pin)
  • 4 x Peripheral
  • 1 x FDD
Dimensions
150mm(W) x 86mm(H) x 160mm(D)
Certifications & Standards
  • 80 PLUS Gold
  • CE/cTUVus/TÜV SÜD/FCC/BSMI/EAC
  • The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

    Warranty and Service

    Package Contents

    • Power Supply Unit
    • AC Power cord
    • 4x Cable straps
    • 1x 24-pin Main power cable
    • 1x ATX 12V 8-pin cable
    • 1x ATX 12V 4+4 pin cable
    • 3x PCIe 6+2 pin cables
    • 1x PCIe 12+4 pin cable
    • 3x SATA cables
    • 1x Peripheral cables
    • 1x floppy adapter cable
    • Mounting screws
    • User's manual
