SKU: 992-63130B
  • 80 PLUS Platinum Certified
  • 1 x +12V Rail
  • 8 x 6+2 pin PCI-E Connectors
  • MTBF: 120,000 hours
Our Price: Login to see price
Availability: Temporarily out of stock


Specifications

Fans
140 mm hydraulic bearing fan
MTBF
120,000 hours
Protection
OCP, OVP, UVP, OPP, SCP, OTP
Version Support
ATX 12V / EPS12V
Current
13A max
Frequency
50Hz - 60Hz
Output Power
1050W
Output Voltage
Output VoltageOutput Current
+3.3V22A
+5V22A
+12V183.33A
-12V0.3A
+5Vsb3A
Input Voltage
100 Vac - 240 Vac
Connectors
  • 1 x Main Power Connector 24 pin
  • 2 x ATX 12V (4+4 Pin)
  • 12 x SATA
  • 8 x PCI-E (6+2 Pin)
  • 4 x Peripheral
  • 1 x FDD
Dimensions
150mm(W) x 86mm(H) x 160mm(D)
Certifications & Standards
  • 80 PLUS Platinum
  • CE/cTUVus/TÜV SÜD/FCC/BSMI/EAC
  • The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

    Warranty and Service

    Package Contents

    • Power Supply Unit
    • AC Power cord
    • 4x Cable straps
    • Mounting screws
    • User's manual
