SKU: 850-247042E
  • 2x LGA3647 Xeon Scalable family
  • Max 7.5TB DR4 2933/2666/2400 ECC Reg (24 DIMMs)
  • 4x 3.5" SATA bays - Hot Swap - RAID 0, 1, 10
  • No onboard LAN
Our Price: Login to see price
Availability: Temporarily out of stock


Specifications

Server Case Form Factor
  • 1U
  • 16.93" x 27.95" x 1.72"
Processor
  • 1st and 2nd Gen Intel Xeon processor Scalable family with maximum TDP of 205W.
  • Socket P
  • Dual (Not Included)
Chipset
Intel C624 Chipset
Type of Memory Supported
  • DDR4 2933/2666/2400 MHz ECC RDIMM, LRDIMM
  • Intel Optane DC Persistent Memory
Maximum Memory Supported
7.5TB
Number of Memory Slots
24
Slots
2 x PCIe x16 via Riser card F1UL16RISER3
Front I/O Ports
  • 2 x USB 3.0 ports
  • 1 x VGA
Rear I/O Ports
  • 3 x USB 3.0 ports
  • 1 x RJ45 Serial A port
  • 1 x VGA
  • 1 x Dedicated Management Port
Video
Integrated 2D video controller
LAN
No onboard LAN
SATA / SAS
    12 x SATA:
    • 2 x SATA 6Gb/s
    • 2 x M.2 - SATA / PCIe
    • 2 x 4-port mini-SAS (SFF-8643)
USB Port (s)
  • 3 x USB 3.0 ports on Back Panel I/O
  • 2 x USB 3.0 ports on Front Panel I/O
Optical Drive(s)
Not Included
Ext. Drive Bays
4 x 3.5"
Power
1100W
Motherboard Manufacturer
Intel S2600WF0R
Manageability
IPMI 2.0 compliant

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

  • Warranty Length: 3 years
  • Warranty Provider: Intel
  • Service Contact:
    1. First 30-day from invoice date: Allstarshop On-line RMA Request
    2. After 30-day from invoice date: Contact Intel at (800) 538-3373
  • Technical Support: Intel (800) 538-3373

Package Contents

  • Intel Server Board S2600WF0 (No onboard LAN) S2600WF0
  • 2 Riser card assembly with 1 slot PCIe x16 riser card F1UL16RISER3
  • 4 3.5” Hot-swap drive bays with drive carriers and drive blanks:
    • 12 Gb SAS backplane FR1304S3HSBP
    • 4 3.5” hot swap drive tool less carriers FXX35HSCAR2

  • 1 Standard control panel assembly FXXFPANEL2
  • 1 Front I/O Panel assembly (VGA and 2 x USB)
  • 1 150mm Backplane I2C cable
  • 1 850mm MiniSAS HD Cable AXXCBL850HDHRT
  • 1 350mm Backplane power cable
  • 1 Air duct
  • 6 Dual rotor system fans FR1UFAN10PW
  • 8 DIMM slot blanks
  • 1 Chassis Stiffener Bar
  • 1 1100W power supply module AXX1100PCRPS
  • 2 CPU heat sinks, FXXCA78X108HS
  • 2 CPU heat sink “No CPU” Label inserts
  • 2 Standard CPU Carrier
  • 1 Power supply bay blank insert
  • 2 Chassis handle (1 set) installed A2UHANDLKIT3
  • 2 AC Power Cord retention strap assembly

Compatible Accessories

CPU

Intel Xeon Silver 4110 8-Core 2.1GHz w/11MB LGA3647 CPU (BOX)
  • 8x Cores / 16x Threads / Turbo Boost: 3.0 GHz
  • Supported Memory: DDR4-2400 ECC
Manufacturer: Intel
Mfg P/N: BX806734110
Availability: Temporarily out of stock

Memory

Kingston 16GB DDR4-2666 ECC Reg CL19 SRx4 288-pin RDIMM
  • PC4-21300
  • Single-rank x4
Manufacturer: Kingston
Mfg P/N: KSM26RS4/16HDI
Availability: Usually ships with 1-2 business days

Networking Card

Intel I350-T4 v2 Gigabit Quad Port PCIe x4 Server Adapter (Bulk)
Manufacturer: Intel
Mfg P/N: I350T4V2BLK
Availability: Temporarily out of stock
Intel X550-T2 2-port 10Gb Ethernet Converged PCIe 3.0 x4 Network Adapter (Retail)
  • Low Power, 10 Gigabit Ethernet (10GbE)
  • 10GBase-T: 55m on CAT6, 100m on CAT6A
  • Backward Compatible with Existing 1000BASE-T Networks
Manufacturer: Intel
Mfg P/N: X550T2
Availability: Temporarily out of stock

Case Accessories

Intel A1UFULLRAIL 1U Premium Rail
Manufacturer: Intel
Mfg P/N: A1UFULLRAIL
Availability: Usually ships with 1-2 business days
Intel A1USHRTRAIL 1U Premium Rail
Manufacturer: Intel
Mfg P/N: A1USHRTRAIL
Availability: Usually ships with 1-2 business days

Power Supplies

Intel AXX1100PCRPS 1100W AC Common Redundant Power Supply (Platinum Efficiency)
Manufacturer: Intel
Mfg P/N: AXX1100PCRPS
Availability: Temporarily out of stock
