Asus RS501A-E12-RS4U-16TWH RS501A-E12-RS4U-16TW AMD SP5 1U Server w/ 2x 1600W PSU

Asus RS501A-E12-RS4U-16TW AMD SP5 1U Server w/ 2x 1600W PSU

Support: (812)282-2787

Asus RS501A-E12-RS4U-16TW AMD SP5 1U Server w/ 2x 1600W PSU

SKU:	850-51055A

1x SP5 AMD EPYC 9005/9004 Series
Max 3072GB DDR5 6400MHz ECC Reg (24 DIMMs)
4x 2.5" bays - Hot Swap
Integrated ASMB11-iKVM (BMC, AST2600) Remote Management

Our Price:	Login to see price
Availability:	Temporarily out of stock

Accessories

: AMD EPYC 9365 36-Core 3.4GHz 192MB Cache CPU (Tray)

: AMD EPYC 9455P 48-Core 3.15GHz 256MB Cache CPU (Tray)

: Kingston 32GB DDR5-5600 ECC Reg CL46 288-pin RDIMM

ASUS RS501A-E12-RS4 was designed for general purpose application. With the front 4 hot-swap bays supporting 2.5” drives. It supports AMD EPYC 9005 series processors or AMD EPYC 9004 series processors, up to 360W. With 2 DIMM per channel design, RS501A-E12 Series supports up to 24 x DIMM slots. With embedded ASMB11-iKVM (BMC, AST2600) and bundled with ASUS Control Center to provide comprehensive out-of-band and in-band management capability.

Description

Specifications

Server Case Form Factor

1U
33.17" x 17.68" x 1.73"

Processor

Single
AMD EPYC 9005/9004 series processors

Chipset

SoC

Type of Memory Supported

DDR5-6400/5600 ECC RDIMM

Maximum Memory Supported

3TB

Number of Memory Slots

Slots

1 x PCIe 5.0 x16 (FHHL)
2 x PCIe 5.0 x16 (LPHL)
1 x OCP 3.0 PCIe 5.0 x16

Rear I/O Ports

2 x USB 3.2 Gen1 ports
1 x VGA
1 x Management port
2 x 1GbE LAN

LAN

Intel I350-AM2 GbE LAN

Ext. Drive Bays

4 x 2.5” Hot-swap Storage Bays

Int. Drive Bays

2 x M.2 socket, with M key, support PCIe 4.0 x4 & SATA mode

Power

1+1 Redundant 1600W 80 PLUS Titanium Power Supply

Motherboard Manufacturer

Asus K14PA-U24-T

Manageability

ASMB11-iKVM

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

Warranty Length: 3 years
Warranty Provider: Asus
Service Contact:
1. First 30-day from invoice date: Allstarshop On-line RMA Request
  This item is returnable for replacement only. It can only be exchanged with the same item.
2. After 30-day from invoice date: Contact Asus at (510)739-3777 Or visit Asus customer service online.
Technical Support: Asus (812)282-2787 or visit Asus technical support online.
