SKU: 960-23531E
  • Supports Intel LGA 2011/1366/1156/1155/1151/1150/775
  • Supports AMD Socket FM2/FM1/AM3+/AM3/AM2+/AM2
  • Heatsink Dimensions: 94(L) x 131(W) x 152(H)mm
  • Fan Speed: 900 ~ 1,700 rpm ± 10%
  • Fan Noise: 18 ~ 30 dBA ± 10%
Our Price: Login to see price
Discontinued - Not orderable


Specifications

Socket Type
Intel
  • 1156
  • 1155
  • 1366
  • 775
AMD
  • AM3
  • AM2+
  • AM2
Fan Speed
1 x 1500 rpm
Fan Bearing Type
Long Life Bearing
General Information
Manufacturer
Zalman Tech Co., LTD
Manufacturer Part Number
CNPS9900MAX-B
Manufacturer Website Address
www.zalmanusa.com
Brand Name
Zalman
Product Model
CNPS9900 MAX
Product Type
Cooling Fan/Heatsink
Interfaces/Ports
Connectors
4-pin
Physical Characteristics
Fan Diameter
1 x 135 mm
Heatsink Height
6"
Weight (Approximate)
1.66 lb
Miscellaneous
Compatibility

Intel CPU:

  • Core i7
  • Core i5
  • Core i3
  • Core i7 Extreme
  • Core 2 Quad
  • Core 2 Duo
  • Core 2 Extreme
  • Pentium Dual Core
  • Pentium D
  • Pentium 4
  • Celeron D

    AMD CPU:

  • Phenom II
  • Athlon II
  • Phenom
  • Athlon FX
  • Athlon X2
  • Athlon
  • Sempron
  • Opteron

    Intel Sockets:

  • LGA 1155
  • LGA 1156
  • LGA 1366
  • LGA 775

    AMD Sockets:

  • AM3
  • AM2+
  • AM2

    • Application/Usage
    Processor

    The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

    Warranty and Service

    • Warranty Length: 1 year
    • Warranty Provider: ZALMAN
    • Service Contact:
      1. First 30-day from invoice date: Allstarshop On-line RMA Request
      2. After 30-day from invoice date: Contact ZALMAN at (714) 693-8880
    • Technical Support: ZALMAN (714) 693-8880

    Package Contents

    • CNPS9900 MAX Cooling Fan/Heatsink
    • Backplate
    • Thermal Grease
    • Resistor
    • Wrench
    • Gold Bolts (Socket 1366)
    • Silver Bolts (Socket 1155 / 1156 / 775 / AMD)
    • Nut (Slide) Caps
    • Nuts
    • Loading Block
    • Double-Sided Tape
    • User's Manual
    • Intel Clip
    • AMD Clip
