SKU: 330-20201A
  • Resolution: 1280 x 1024
  • Brightness: 250 cd/m2
  • Contrast Ratio: 5,000,000:1 (Dynamic)
  • DVI-D / VGA
Our Price: Login to see price
Discontinued - Not orderable


Specifications

Viewable Area
18.5"
Brightness
250 cd/m2
Contrast Ratio
1000:1, 5M:1(DFC)
Response Time
5 ms
Viewing Angle
  • Horizontal: 170°
  • Vertical: 160°
    • Pixel Pitch
    0.294mm
    Resolution
    1280 x 1024
    Horizontal Frequency
    30~83kHz
    Vertical Frequency
    56~75Hz
    Analog Input
    15-pin D-sub
    Digital Input
    DVI-D
    Built-in Speakers
    No
    Built-in USB Hub
    No
    Built-in TV Tuner
    No
    Pivot Function
    No
    Power Consumption
    25W
    Dimensions
    16.1" x 8.2" x 16.9" (W x D x H)
    Wall Mount (VESA)
    75mm x 75mm
    Display Type
    LCD display / TFT active matrix - LED backlight
    TFT Technology
    TN
    Depth
    8.3 in
    Height
    16.7 in
    Weight
    5.5 lbs
    Display
    Diagonal Size
    19"
    Max Resolution
    1280 x 1024
    Color Support
    16.7 million colors
    Max Sync Rate (V x H)
    75 Hz x 83 kHz
    Display Positions Adjustments
    Tilt
    Tilt Angle
    20
    Signal Input
    DVI-D, VGA
    Features
    sRGB color management, f-ENGINE technology, HDCP, Photo Effect
    Image Aspect Ratio
    5:4
    Image Brightness
    250 cd/m2
    Image Contrast Ratio
    5000000:1 (dynamic)
    Image Max H-View Angle
    170
    Image Max V-View Angle
    160
    Video Input
    Analog Video Signal
    RGB
    Digital Video Standard
    Digital Visual Interface (DVI)
    Expansion / Connectivity
    Interfaces
    1 x VGA - 15 pin HD D-Sub (HD-15)
    1 x DVI-D - 24 pin digital DVI
    Miscellaneous
    Flat Panel Mount Interface
    75 x 75 mm
    Compatible with Windows 7
    "Compatible with Windows 7" software and devices carry Microsoft’s assurance that these products have passed tests for compatibility and reliability with 32-bit and 64-bit Windows 7.
    Compliant Standards
    FCC Class B certified, CE, UL, TUV GS, cUL, DDC-2B, ISO 13406-2, SEMKO, TCO '05
    Power
    Form Factor
    Internal
    Voltage Required
    AC 120/230 V
    Power Consumption Operational
    25 Watt
    Power Consumption Stand by / Sleep
    0.2 Watt
    Environmental Standards
    ENERGY STAR Qualified
    Yes
    Dimensions & Weight Details
    Dimensions & Weight Details
    Without stand - 16.1 in x 2.3 in x 13.3 in x 5.3 lbs
    With stand - 16.1 in x 8.3 in x 16.7 in x 5.5 lbs

    The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

    Warranty and Service

    Package Contents

    • Monitor
    • Power Cord
    • Signal Cable
    • Manual
    • Install Disk
