SKU: 541-19513
Our Price: Login to see price
Discontinued - Not orderable


Specifications

Physical Characteristics
Material
Metal
Form Factor
Rack-mountable
Dimensions
1.75" Height x 7.75" Width x 3" Depth
Weight (Approximate)
1.40 lb
General Information
Manufacturer
Iogear, Inc
Manufacturer Part Number
GVS148TX
Manufacturer Website Address
Brand Name
Iogear
Product Model
GVS148TX
Product Type
Video Extender
Technical Information
Number of Input Devices
1
Number of Output Devices
1 Local
Graphics Modes
WUXGA
Graphics Resolution
1920 x 1200
Video Bandwidth
225 MHz
Connectivity Media
Category 6
Operating Range
984 ft
Interfaces/Ports
Input Ports
1 x 15-pin HD-15 Male VGA
Output Ports
1 x 15-pin HD-15 Female VGA
Environmental Conditions
Temperature
32°F (0°C) to 122°F (50°C) Operating
Humidity
0 to 80% Relative Humidity Non-condensing
Miscellaneous
Compatibility

IOGEAR GVE140RX Receiver

Green Compliance
Yes
Green Compliance Certificate/Authority
RoHS

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

  • Warranty Length: 1 year
  • Warranty Provider: IOGEAR
  • Service Contact:
    1. First 30-day from invoice date: Allstarshop On-line RMA Request
    2. After 30-day from invoice date: Contact IOGEAR at 949-428-1111
  • Technical Support: IOGEAR 949-428-1111

Package Contents


  • GVS148TX Video Extender
  • 1 x Power Adapter
  • 1 x Rack Mount Kit
  • 1 x Foot Pad Set
  • 1 x Grounding Wire
  • 1 x Quick Start Guide
  • 1 x Warranty Card
